Inflatable Drum vs Spindle Sander: How to Sand Inside Curves Smoothly (80–400 Grit Finish Comparison)

Curved furniture parts, round table aprons, and sculpted handles require even pressure along concave profiles. Two common tools—inflatable drums and spindle sanders—deliver very different results. Understanding their behavior with different grits helps you shape faster and finish smoother without facets or burn marks.

Why Inside-Curve Sanding Needs Control

Unlike flat work, concave surfaces concentrate pressure in a narrow band. Hard drums can dig in, while overly soft ones round edges. Matching drum flexibility, diameter, and grit keeps curves true and symmetrical through each sanding stage.

Recommended Tools

• Inflatable sanding drum with variable air pressure.
• Oscillating spindle sander with assorted rubber sleeves.
• Dust extraction or shop vacuum.
• Calipers or contour gauge for profile checking.
• Safety glasses and hearing protection.

Best Grit Sequence for Curved Work

• 80 grit: rough-shape curves and remove tool marks.
• 150 grit: refine radius and smooth ridges.
• 220 grit: final shape before finish sanding.
• 400 grit: pre-finish smoothing for paint or varnish.

Step-by-Step: Comparing Inflatable vs Spindle Results

1. Set up identical test blanks. Use ¾-in hardwood or MDF curves cut to matching radii.
2. Inflatable drum test. Inflate to medium firmness. Sand with 80 → 220 grit, letting the drum flex slightly to follow the contour. Note how it feathers transitions smoothly.
3. Spindle sander test. Use fixed-hardness sleeves of the same grits. Observe sharper definition but higher risk of flats on tight curves.
4. Inspect surfaces. The inflatable drum leaves gentle, diffuse scratch patterns; the spindle yields crisp, linear grain following the oscillation path.
5. Finish both with 400 grit. Use light touch—both tools can burnish end grain quickly at fine stages.

Special Cases

For softwoods or veneered parts, reduce inflation pressure or use finer grits to avoid sanding through. When shaping very tight inside radii (<25 mm), switch to a spindle with smaller diameter to maintain control.

Pro Tips

• Vary drum pressure to tune aggressiveness—softer for blending, firmer for shaping.
• Keep sleeves clean; loaded abrasive causes chatter and pigtails.
• Alternate grain direction every grit stage to reveal missed scratches.

Aftercare

• Vacuum dust from curves before finishing—fine residue hides in recesses.
• Wipe with mineral spirits to preview final sheen and detect ridges.
• Store inflatable drums slightly deflated to preserve bladder life.

FAQs

• Which tool gives a smoother finish? Inflatable drums generally blend better; spindles cut flatter and faster.
• Can I use both? Yes—rough with spindle, finish with inflatable for best control.
• Do I sand with or across the curve? Follow the curve lengthwise to maintain flow lines and avoid cross-ridges.
